TA770E3/TA770XE3/TA790XE3
57
TA770E3/TA770XE3 TA790XE3
Gniazdo PCI x3 Gniazdo PCI x3
Gniazdo PCI Express Gen2 x16 x1 Gniazdo PCI Express Gen2 x16 x1
Gniazda
Gniazdo PCI Express Gen2 x1 x2 Gniazdo PCI Express Gen2 x1 x2
Złącze napędu dyskietek x1 Złącze napędu dyskietek x1
Złącze IDE x1 Złącze IDE x1
Złącze SATA x6 Złącze SATA x6
Złącze panela przedniego x1 Złącze panela przedniego x1
Przednie złącze audio x1 Przednie złącze audio x1
Złącze wejścia CD x1 Złącze wejścia CD x1
Złącze wyjścia S/PDIF x1 Złącze wyjścia S/PDIF x1
Złącze g łówkowe wentylatora procesora x1 Złącze główkowe wentylatora procesora x1
Złącze g łówkowe wentylatora systemowego x2 Złącze główkowe wentylatora systemowego x2
Złącze g łówkowe kasowania CMOS x1 Złącze głó wkowe kasowania C MOS x1
Złącze USB x3 Złącze USB x3
Złącze Port szeregowy x1 Złącze Port szeregowy x1
Złącze zasilania (24 pinowe) x1 Złącze zasilania (24 pinowe) x1
Złącza
wbudowane
Złącze zasilania (4 pino we) x1 Złącze zasilania (4 pino we) x1
Back Panel
I/O
Klawiatura PS/2 x1
Mysz PS /2 x1
Port LAN x1
Port USB x6
Gniazdo audio x3
Klawiatura PS/2 x1
Mysz PS /2 x1
Port LAN x1
Port USB x6
Gniazdo audio x3
Wymiary
płyty
220mm (S) X 305 mm (W) 220mm (S) X 305 mm (W)
Obsluga
systemu
operacyjne
go
Windows XP / Vista / 7
Biostar zastrzega sobie prawo dodawania lub
odwoływania obsług i dowo ln ego systemu
operacyjnego bez powiadomienia.
Windows XP / Vista / 7
Biostar zastrzega sobie prawo dodawania lub
odwoływania obsług i dowo ln ego systemu
operacyjnego bez powiadomienia.
