TA770E3/TA770XE3/TA790XE3
59
TA770E3/TA770XE3 TA790XE3
Слот PCI x3 Слот PCI x3
Слот PCI Express Gen2 x16 x1 Слот PCI Express Gen2 x16 x1
Слоты
Слот PCI Express Gen2 x1 x2 Слот PCI Express Gen2 x1 x2
Разъём НГ МД x1 Разъём НГ МД x1
Разъём IDE x1 Разъём IDE x1
Разъём SATA x6 Разъём SATA x6
Разъём на лицевой панели x1 Разъём на лицевой панели x1
Входной звуковой разъём x1 Входной звуковой разъём x1
Разъём ввода для CD x1 Разъём ввода для CD x1
Разъём вывода для S/PDIF x1 Разъём вывода для S/PDIF x1
Контактирующее приспособление
вентил ятора центрального процессора x1
Контактирующее приспособление
вентил ятора центрального процессора x1
Контактирующее приспособление
вентил ятора системы x2
Контактирующее приспособление
вентил ятора системы x2
Открытое контактирующее
приспособление CMOS x1
Открытое контактирующее
приспособление CMOS x1
USB-разъём x3 USB-разъём x3
Разъём Последовательный порт x1 Разъём Последовательный порт x1
Разъем питания (24 вывод) x1 Разъем питания (24 вывод) x1
Встроенны
й разъём
Разъем питания (4 вывод) x1 Разъем питания (4 вывод) x1
Задняя
панель
средств
ввода-выв
ода
Клавиатура PS/2 x1
Мышь PS/2 x1
Порт LAN x1
USB-порт x6
Гнездо для подключения наушников x3
Клавиатура PS/2 x1
Мышь PS/2 x1
Порт LAN x1
USB-порт x6
Гнездо для подключения наушников x3
Размер
панели
220мм (Ш) X 305 мм (В) 220мм (Ш) X 305 мм (В)
Поддержка
OS
Windows XP / Vista / 7
Biostar сохраняет за собой право добавлять
или удал ять средства обеспечения для OS с
или без предварительного уведомления.
Windows XP / Vista / 7
Biostar сохраняет за собой право добавлять
или удал ять средства обеспечения для OS с
или без предварительного уведомления.
