Motherboard Manual
62
JAPANESE
TA770E3/TA770XE3 TA790XE3
CPU
Socket AM3
AthlonII / Phenom II プロセッサ
AMD 64アーキテクチャでは、32ビットと64ビット計
算が可能です
ハイパートランスポート3.0サポートします
(最高のワット: 125W)
Socket AM3
AthlonII / Phenom II プロセッサ
AMD 64アーキテクチャでは、32ビットと64ビット計
算が可能です
ハイパートランスポート3.0サポートします
(最高のワット: 125W)
FSB
5.2 GT/sのバンド幅までハイパートランスポート3.0
をサポートします
5.2 GT/sのバンド幅までハイパートランスポート3.0
をサポートします
チップセット
AMD 770
AMD SB710
AMD 790X
AMD SB750
メインメモリ
DDR3 DIMMスロット x 4
各DIMMは 256MB/512MB/1GB/2GB/4GB
DDR3をサポート
最大メモリ容量16GB
デュアル チャンネルモードDDR3メモリモジュール
DDR3 800 / 1066 / 1333をサポート
DDR3 1600をサポート (OC)
登録済みDIMMとECC DIMMはサポートされません
DDR3 DIMMスロット x 4
各DIMMは 256MB/512MB/1GB/2GB/4GB
DDR3をサポート
最大メモリ容量16GB
デュアル チャンネルモードDDR3メモリモジュール
DDR3 800 / 1066 / 1333をサポート
DDR3 1600をサポート (OC)
登録済みDIMMとECC DIMMはサポートされません
Super I/O
ITE IT8718F
もっとも一般に使用されるレガシーSuper I/O機能を
採用しています。
低ピンカウントインターフェイス
環境コントロールイニシアチブ、
H/Wモニター
ファン速度コントローラ/ モニター
ITEの「スマートガーディアン」機能
ITE IT8718F
もっとも一般に使用されるレガシーSuper I/O機能を
採用しています。
低ピンカウントインターフェイス
環境コントロールイニシアチブ、
H/Wモニター
ファン速度コントローラ/ モニター
ITEの「スマートガーディアン」機能
IDE
AMD SB710
Ultra DMA 33 / 66 / 100 / 133バスマスタモード
PIO Mode 0~4のサポート、
AMD SB750
Ultra DMA 33 / 66 / 100 / 133バスマスタモード
PIO Mode 0~4のサポート、
SATA II
AMD SB710
最高3 Gb/秒のデータ転送速度
SATAバージョン2.0仕様に準拠。
RAID 0,1,1+0のサポート
AMD SB750
最高3 Gb/秒のデータ転送速度
SATAバージョン2.0仕様に準拠。
RAID 0,1,5,1+0のサポート
LAN
Realtek RTL 8111DL
10 / 100 / 1000 Mb/秒のオートネゴシエーション
半/全二重機能
Realtek RTL 8111DL
10 / 100 / 1000 Mb/秒のオートネゴシエーション
半/全二重機能
サウンド
Codec
ALC662
ハイデフィニションオーディオのサポート
5.1 チャンネルオーディオアウト
ALC662
ハイデフィニションオーディオのサポート
5.1 チャンネルオーディオアウト
