Biostar A740G3L Версия 6.x [14/49] Pci1 pci2 peripheral component interconnect slots

Motherboard Manual

PEX16_1: PCI-Express X16 Slot

- PCI-Express 2.0 compliant.

- Maximum theoretical realized bandwidth of 4GB/s simultaneously per

direction, for an aggregate of 16GB/s totally.

- PCI-Express supports a raw bit-rate of 2.5Gb/s on the data pins.

PEX16_1

PCI1~PCI2: Peripheral Component Interconnect Slots

This motherboard is equipped with 2 standard PCI slots. PCI stands for

Peripheral Component Interconnect, and it is a bus standard for expansion

cards. This PCI slot is designated as 32 bits.

PCI1

PCI2
