A740G3L
41
SPEC
Przednie złącze audio x1 Obsługa funkcji audio na panelu przednim
Złącze wyjścia S/PDIF x1 Obsługa funkcji cyfrowego wyjścia audio
Złącze główkowe wentylatora procesora
x1
Zasilanie wentylatora procesora (z funkcją Smart Fan)
Złącze głó wkowe wentylatora
systemowego x1
Zasilanie wentylatora systemowego
Złącze głó wkowe kasowania CMOS x1
Złącze USB x2
Każde złącze obs ługuje 2 porty USB na panelu
przednim
Złącze zasilania (24 pinowe) x1
Złącze zas ilania (4 pino we) x1
Port szeregowy x1
Złącze Port drukarki x1 Każde złącze obs ługuje 1 Port drukarki
Back Panel
I/O
Klawiatura PS/2 x1
Mysz PS /2 x1
Port VGA x1
Port LAN x1
Port USB x4
Gniazdo audio x3
Wymiary
płyty
182 mm (S) X 235 mm (W)
Funkcje
specjalne
Obsługa RAID 0 / 1 / 10
Obsluga
systemu
operacyjne
go
Windows XP / Vista / 7
Biostar zastrzega sobie prawo dodawania lub
odwoływania obsług i dowo ln ego s ystemu
operacyjnego b ez powiado mienia.
