Motherboard Manual
46
JAPANESE
仕様
CPU
Socket AM3
AMD Sempron / Phenom II / Athlon II プ
ロセッサ (最高のワット: 95W)
AMD 64アーキテクチャでは、32ビットと64ビット計算が可
能です
ハイパートランスポート2.0とクールアンドクワイアットを
サポートします
FSB
2 GT/sのバンド幅までハイパートランスポー
ト2.0をサポートします
チップセッ
ト
AMD 740G
AMD SB710
メインメモ
リ
DDR3 DIMMスロット x 2
最大メモリ容量8GB
各DIMMは 512MB/1GB/2GB/4GB DDR3
をサポート
デュアル チャンネルモードDDR3メモリモジュール
DDR3 800 / 1066 / 1333 をサポート
登録済みDIMMとECC DIMMはサポートされません
Super I/O
ITE 8721
もっとも一般に使用されるレガシーSuper I/O
機能を採用しています。
低ピンカウントインターフェイス
環境コントロールイニシアチブ、
H/Wモニター
ITEの「スマートガーディアン」機能
グラフィッ
クス
AMD 740Gチップセットに統合
最大の共有ビデオメモリは512MBです
Avivo のサポート
IDE 統合IDEコントローラ
Ultra DMA 33 / 66 / 100 / 133バスマスタモード
PIO Mode 0~4のサポート、
SATA 統合シリアルATA コントローラ
最高3Gb/秒のデータ転送速度
SATAバージョン2.0仕様に準拠。
LAN Realtek RTL 8103EL 10 / 100 Mb/秒のオートネゴシエーション
HDオーディ
オのサポー
ト
ALC662 / VT1708B
5.1チャンネルオーディオアウト
ハイデフィニションオーディオのサポート
PCI Express X16スロット x1
スロット
PCIスロット x2
フロッピーコネクタ x1 各コネクタは2つのフロッピードライブをサポートします
IDEコネクタ x1 各コネクタは2つのIDE デバイスをサポートします
オンボード
コネクタ
SATAコネクタ x4 各コネクタは1つのSATAデバイスをサポートします
