Motherboard Manual
38
PORTUGUESE
ESPECIFICAÇÕES
CPU
Socket AM3
Processadores AMD Sempron / Phenom II
/ Athlon II (Watt máximo: 95W)
A arquitectura AMD 64 permite u ma computação de
32 e 64 bits
Suporta as tecno log ias Hyper Transport 2.0
FSB
Suporta a tecnologia HyperTransport 2.0
com uma largura d e banda até 2 GT/s
Chipset
AMD 740G
AMD SB710
Especificaç
ão Super
I/O
ITE 8721
Proporciona as funcionalidades mais
utilizadas em termos da especificação
Super I/O.
Interface LPC (Low Pin Count).
In iciat ivas par a contro lo do amb iente
Monitorização do hardware
Função "S mart Gu ardian" da ITE
Memória
principal
Ranhuras DIMM DDR3 x 2
Capacidad e máx ima d e memór ia: 8GB
Cada módulo DIMM suporta uma
memória DDR3 de 512MB/
1GB/2GB/4GB
Módulo de memória DDR3 de canal duplo
Suporta módulos DDR3 800 / 1066 / 1333
Os módulos DIMM registados e os DIMM ECC não são
suportados
Placa
gráfica
Integrada no chipset AMD 740G
Memória de vídeo máxima partilhada: 512 MB
Suporta as funções Avivo
IDE
Controlador IDE integrado
Modo Bus master Ultra DMA 33 / 66 / 100 / 133
Suporta o modo PIO 0~4,
SATA
Controlador Serial ATA integrado
Velocidades de transmissão de dados até 3 Gb/s.
Compat ibilidade co m a especificação SATA versão 2.0.
LAN
Realtek RTL 8103EL Auto negociação de 10 / 100 Mb/s
Suporte
para áudio
de alta
definição
ALC662 / VT1708B
Saída de áudio de 5.1 canais
Suporta a especificação High-Definition Audio
Ranhura PCI Express X16 x1
Ranhuras
Ranhura PCI x2
Conector da unidade de disquetes x1 Cada conector suporta 2 unidades de disquetes
Conectores
na placa
Conector IDE x1 Cada conector suporta 2 dispositivos IDE
