Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
KBMS1
USB1
R J45USB 1
VGA1
AUDIO1
JSPDIFOUT1
J_PRINT1
JCMOS1
JUSBV2
F_USB2
F_USB1
PANEL1 SATA1 SATA2
SYS_FAN1
SATA3
SATA4
BIOS
AMD
SB710
IDE1
BATTERY
AMD
740G
D3_1DR A
D3_1
DR B
CPU_FAN1
ATXPWR1
Socket AM3
LAN
Super
I/O
Codec
F_AUDIO1
PEX 16_1
PCI1
PCI2
FDD1
ATXPWR2
J_COM1
JUSBV1
Note: represents the 1■
st
pin.
