A740G3L
39
ESPECIFICAÇÕES
Conector SATA x4 Cada conector suporta 1 dispositivo SATA
Conector do painel frontal x1 Para suporte de várias funções no painel frontal
Conector de áudio frontal x1 Suporta a fun ção de áudio no painel frontal
Conector de saída S/PDIF x1 Suporta a saída de áudio digital
Conector da ventoinha da CPU x1
Alimentação da ventoinha da CPU (com a função
Smart Fan)
Conector da ventoinha do s istema x1 Alimentação da ventoinha do sistema
Conector para limpeza do CMOS x1
Conector USB x2 Cada conector suporta 2 portas USB no painel frontal
Conector de alimentação x1
(24 pinos)
Conector de alimentação x1
(4 p inos)
Porta série x1
Conector da para impressora x1 Cada conector suporta 1 Porta para impressora
Entradas/S
aídas no
painel
traseiro
Tec lad o PS /2 x 1
Rato PS/2 x1
Porta VGA x1
Porta LAN x1
Porta USB x4
Tomada de áudio x3
Tamanho
da placa
182 mm (L) X 235 mm (A)
Característi
cas
especiais
Suporta as funções RAID 0 / 1 / 10
Sistemas
operativos
suportados
Windows XP / Vista / 7
A Biostar reserva-se o direito de adicionar ou remover
suporte para qualquer sistema operativo com ou sem
av iso prév io.
