Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM3
AMD Sempron / Phenom II / Athlon II
processors (Maximum Watt: 95W )
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 2.0
FSB
Support Hyper Transport 2.0
Supports up to 2 GT/s Bandwidth
Chipset
AMD 740G
AMD SB710
Super I/O
ITE 8721
Provides the most commonly used legacy
Super I/O functionality
Low Pin Count Interface
Environment Control in it iatives
H/W Monitor
ITE's "Smart Guardian" funct ion
Main
Memory
DDR3 DIMM Slots x 2
Max Memory Capacity 8GB
Each DIMM supports 512MB/
1GB/2GB/4GB DDR3
Dual Channel Mode DDR3 memory modu le
Supports DDR3 800 / 1066 / 1333
Registered DIMM and ECC D IMM is not supported
Graphics Integrated in AMD 740G Chipset
Max Shared V ideo Memory is 512 MB
Avivo supported
IDE Integr ated IDE Contro ller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4
SATA II Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s
SATA Version 2.0 specif ic at ion co mp liant
LAN Realtek RTL 8103EL 10 / 100 Mb/s auto negotiation
Sound ALC662 / VT1708B
5.1 channels audio out
High Definition Audio
PCI Express X16 slot x1 Supports PCI-E X16 expansion card
Slots
PCI slot x2 Supports PCI expansion cards
Floppy Connector x1 Each connector supports 2 Floppy drives
IDE Connector x1 Each connector supports 2 IDE devices
SATA Connector x4 Each connector supports 1 SATA device
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
On Board
Connectors
S/PDIF out Connector x1 Supports digital audio out function
