Motherboard Manual
36
SPANISH
Especificación
CPU
Conector AM3
Procesadores AMD S empron / Phenom II
/ Athlon II (Vatio máximo: 95W)
La arquitectura AMD 64 permite el procesado de 32 y
64 bits
Soporta las tecnologías Hyper Transport 2.0
FSB
Admite HyperTransport 2.0 con un ancho
de banda de hasta 2 GT/s
Conjunto
de chips
AMD 740G
AMD SB710
Súper E/S
ITE 8721
Le ofrece las funcionalidades heredadas
de uso más común Súper E/S.
Interfaz de cuenta Low Pin
In iciat ivas de control d e entorno,
Monitor hardware
Función "Guardia inteligente" de ITE
Memoria
principal
Ranuras DIMM DDR3 x 2
Capacidad máxima de memoria de 8GB
Cada DIMM admite DDR de
512MB/1GB/2GB/4GB
Módulo de memoria DDR3 de canal Doble
Admite DDR3 de 800 / 1066 / 1333
No admite DIMM registrados o DIMM compatibles con
ECC
Gráficos
Integrados en el conjunto de chips AMD
740G
Memoria máxima de vídeo compartida de 512 MB
Admite Avivo
IDE Controlador IDE integrado
Modo bus maestro Ultra DMA 33 / 66 / 100 / 133
Soporte los Modos PIO 0~4,
SATA Controlador ATA Serie Integrado
Tasas de transferencia de hasta 3 Gb/s.
Compat ib le con la versión SATA 2.0.
Red Local Realtek RTL 8103EL Negociación de 10 / 100 Mb/s
Soporte de
sonido HD
ALC662 / VT1708B
Salida de sonido de 5.1 canales
Soporte de sonido Alta Definición
Ranura PCI Express X16 X1
Ranuras
Ranura PCI X2
Conector disco flexible X1 Cada conector soporta 2 unidades de disco flexible
Conector IDE X1 Cada conector soporta 2 dispositivos IDE
Conector SATA X4 Cada conector soporta 1 dispositivos SATA
Conector de p anel frontal X1 Soporta instalaciones en el p anel frontal
Conectores
en placa
Conector de sonido frontal X1 Soporta funciones de sonido en el panel frontal
