A760G M2+ BIOS Manual
11
Hardware Health Configuration
This item shows the system temperature, fan speed, and voltage information.
Advanced
Hardware Health Configuration
H/W Health Function [ Enabled]
Shutdown Temperature [ Disabled]
CPU Temperature
CPU FAN Speed(JCFAN1)
SYS FAN Speed(JSFAN1)
CPU Voltage
Chip Voltage
+3.30V
+12.0V
DDR Voltage
HT Voltage
5VSB
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, Amer ican Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Enables Hardware
Health Monitoring
Device.
H/W Health Function
If with a monitoring system, the system will show PC health status during POST
stage.
Options: Enabled (Default) / Disabled
Shutdown Temperature
This item allows you to set up the CPU shutdown Temperature. This item is only
effective under Windows 98 ACPI mode.
Options: Disabled (Default) / 70℃/158℉ / 60℃/140℉ / 65℃/149℉ / 75℃/158℉
/ 80℃/158℉ / 85℃/158℉ / 90℃/158℉ / 95℃/158℉
