A760G M2+ BIOS Manual
28
6 Performance Menu
This submenu allows you to change voltage and clock of various devices.
(However, we suggest you use the default setting. Changing the voltage and clock
improperly may damage the device.)
Notice
z Beware of that setting inappropriate values in items of this menu may cause
system to malfunction.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset Performance
vxx.xx (C)Copyright 1985-200x, Amer ican Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Exit
Change CPU voltage
value.
Performance Settings
WARNING: Setting wrong values in below sections
may cause system to m alfunction.
CPU Overvoltage [ StartUp]
Memory Overvoltage [ 1.95V]
Chipset Overvoltage [ 1.15V]
HT Overvoltage [ 1.20V]
CPU Frequency [ 200]
> DRAM Timing Configuration
> Hyper Transport Configuratio n
> Memory Configuration
> CPU FID/VID Control
CPU Overvoltage
This item allows you to select CPU Voltage Control.
Options: StartUp (Default) / +0.10V / +0.20V / +0.30V
Memory Overvoltage
This item allows you to select DDR Voltage Control.
Options: 1.95V (Default) / 2.05V / 2.15V / 2.25V / 2.35V / 2.45V / 2.55V / 2.65V
Chipset Overvoltage
This item allows you to select NB/SB Voltage Control.
Options: 1.15V (Default) / 1.20V / 1.25V / 1.30V
