A760G M2+ BIOS Manual
25
PCI Express Configuration
BIOS SETUP U TILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Update
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
PCI Express Configuration
> Port #02 Features
> NB-SB Port Features
GPP Slots Power Limit, W [25 ]
GPP Slots Power Limit, W
Options: 25 (Default) / 0-255
Port #02 Features
BIOS SETUP U TILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Gen2 High Speed Mode [Dis abled]
Link ASPM [Dis abled]
Link Width [Aut o]
Slot Power Limit,W [75 ]
Auto - RC only
advertize Gen2
capability.
Gen2 High Speed Mode
Options: Disabled (Default) / Auto
Link ASPM
Options: Disabled (Default) / L0s / L1 / L0x & L1
