A760G M2+ BIOS Manual
32
DCT Unganged Mode
This item controls the DRAM controller ganged (128bit*1) / unganged (64bit*2)
dual-channel operation mode. If two DRAM modules with different size are
installed, using unganged mode can still make it run in dual-channel operation.
Options: Auto (Default) /Always
Power Down Enable
This item controls the DRAM power down function.
Options: Enabled (Default) / Disabled
Power Down Mode
This item allows you to select the DRAM power down mode.
Options: Channel (Default) / CS
ECC Configuration
BIOS SETU P U TILITY
vxx .xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
ECC Configurat ion
ECC Mode [Disabled]
DRAM ECC Ena ble [Disabled]
DRAM SCRUB R EDIRECT [Disabled]
4-Bit ECC Mo de [Disabled]
DRAM BG Scru b [Disabled]
Data Cache B G Scrub [Disabled]
L2 Cache BG Scrub [Disabled]
L3 Cache BG Scrub [Disabled]
Set the level of ECC
protection. Note: The
Super ECC mode
dynamically sets the
DRAM scrub rate so
all of memory is
scrubbed in 8 hours.
Performance
ECC Mode
This item allows you to select the DRAM ECC Mode.
Options: Disabled (Default) / Basic / Good / Super / Max / User
DRAM ECC Enabled
Options: Disabled (Default) / Enabled
