A760G M2+ BIOS Manual
34
CPU FID/VID Control (for AM2+ CPU)
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, Amer ican Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
CPU FID/VID Control
Custom P-States [ Disabled]
Core FID [ x11.5 2300MHz]
Core DID [ Divided by 1]
Core VID [ 1.2500 V]
NB FID [ 2000 Mhz]
Performance
Options
Custom P-States
This item allows you to select the P-States controlling.
Options: Disabled (Default) / Enabled
Core FID
This item allows you to select the Ratio/Frequency of AM2+ CPU.
Options: x8.0 1600MHz ~ x31.5 6300MHz (Differed by CPU)
Core DID
Options: Divided by 1 (Default) / Divided by 2 / Divided by 4 / Divided by 8 /
Divided by 16
Core VID
This function allows you to adjust the voltage of CPU.
Options: 0.0125V ~ 1.5500V (Differed from CPU).
NB FID
This item allows you to select the Frequency of NB chip.
Options: 2000MHz (Default) / 800MHz ~ 7000MHz
