A760G M2+ BIOS Manual
29
HT Overvoltage
This item allows you to select HT Voltage Control.
Options: 1.20V (Default) / 1.30V / 1.40V / 1.50V
CPU Frequency
This item allows you to select the CPU Frequency.
Options: 200 (MHz) (Default) / 200-600
DRAM Timing Configuration
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, Amer ican Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
DRAM Timing Config uration
Memory Clock Mode [ Auto]
Memclock Value [ DDR2-400]
DRAM Timing Mode [ Auto]
Memory CLK :
Memory CLK :
CAS Latency(Tcl) :
RAS/CAS Delay(Trcd) :
Row Precharge Time(Trp):
Min Active RAS(Tras) :
RAS/RAS Delay(Trrd) :
Row Cycle (Trc) :
Select the DRAM
Frequency programming
method. If Auto,
the DRAM speed will
be based on SPDs.
If Limit, the DRAM spe
will not exceed the
specified value. If
Manual, the DRAM speed
specified will be
programmed regardless.
Performance
Memory Clock Mode
This item allows you to control the Memory Clock.
Options: Auto (Default) / Limit / Manual
Memclock Value
This item allows you to set the Memory Clock.
Options: DDR2-400 (Default) / DDR2-533 / DDR2-667 / DDR2-800
