A760G M2+ BIOS Manual
23
SATA IDE Combined Mode
This option controls the SATA/PATA combined mode.
Options: Enabled (Default) / Disabled
RS780 Configuration
BIOS SETUP U TILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
RS780 Configuration
> PCI Express Configuration
Primary Video Controller [PCI -GFX0-GPP-IGFX]
NB Power Management Features [Aut o]
> Internal Graphics Configuration
Internal Graphics Conf
Internal Graphics Configuration
BIOS SETUP U TILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Internal Graphics Configuration
UMA Frame Buffer Size [Aut o]
GFX Engine Clock Override [Dis able]
FB Location [Abo ve 4G]
NB Azalia [Ena ble]
Internal Graphics Mode [UMA ]
Surround View [Dis abled]
Options
Disable
UMA
