A760G M2+ BIOS Manual
33
DRAM Scrub Redirect
Options: Disabled (Default) / Enabled
4-bit ECC Mode
Options: Disabled (Default) / Enabled
DRAM BG Scrub/Data Cache BG Scrub/L2 Cache BG Scrub/L3 Cache BG Scrub
Options: Disabled (Default) / 40ns / 80ns / 160ns / 320ns / 640ns / 1.28us / 2.56us /
5.12us / 10.2us / 20.5us / 41.0us / 81.9us / 163.8us / 327.7us / 655.4us /
1.31ms / 2.62ms / 5.24ms / 10.49ms / 20.97ms / 42.00ms / 84.00ms
CPU FID/VID Control (for AM2 CPU)
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, Amer ican Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
CPU FID/VID Control
Processor Multiplier [ Auto]
Processor Voltage [ Auto]
Performance
Options
Auto
x4.0 800 MHz
x4.5 900 MHz
x5.0 1000 MHz
Reserved
x6.5 1300 MHz
Reserved
x7.5 1500 MHz
Processor Multiplier
This item allows you to select CPU frequency.
Options: Auto (Default) / x4.0 800 MHz ~ x13.0 2600 MHz
Processor Voltage
This item allows you to select CPU voltage.
Options: Auto (Default) / 0.800 V ~ 0.950 V
