TA790GXBE BIOS Manual
11
Control Mode
This item provides several operation modes of the fan.
Options: Quiet / Performance / Manual
Fan Ctrl OFF(℃ )
When CPU temperature is lower than this value, the Fan will keep lowest rpm
without PWM control.
Options: 0~127 (℃)
Fan Ctrl On(℃ )
When CPU temperature is higher than this value, the Fan controller will turn on.
Options: 0~127 (℃)
Fan Ctrl Start Value
When CPU/System temperature arrives to the set value, the CPU/System fan will
work under Smart Fan Function mode.
Options: 0~127
Fan Ctrl Sensitive
Increasing the value will raise the speed of CPU/System fan.
Options: 1~127
Hardware Health Configuration
This item shows the system temperature, fan speed, and voltage information.
Advanced
Hardware Health Co nfiguration
H/W Health Functio n [Enabled]
Shutdown Temperatu re [Disabled]
CPU
SYS Temperature
CPU Fan
System1 Fan
System2 Fan
CPU Vcore
HT/Chip Voltage
+3.30V
+5.00V
+12.0V
DDR Voltage
CPU NB Voltage
Temperature
BIOS SETUP UTILITY
vxx.xx (C)Copyright 198 5-200x, American Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Enables Hardware
Health Monitorin g
Device.
