TA790GXBE BIOS Manual
26
PCI Express Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Update
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
PCI Express Configuration
GPP Slots Power Limit, W [25 ]
> Port #02 Features
> Port #04 Features
> Port #06 Features
> Port #07 Features
> Port #09 Features
> Port #10 Features
> NB-SB Port Features
GFX Dual Slot Configuration [Disabled]
> Port #05 Features
Options
Auto
Disabled
Enabled
GFX Dual Slot Configuration
Options: Disabled (Default) / Auto / Enabled
GPP Slots Power Limit, W
Options: 25 (Default) / 0-255
Port #02/04/05/06/07/09/10 Features
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Gen2 High Speed Mode [Auto]
Link ASPM [Disabled]
Link Width [Auto]
Slot Power Limit, W [75]
Compliance Mode [Disabled]
Auto - RC only
advertize Gen2
capability.
Gen2 High Speed Mode
Options: Auto (Default) / Disabled / Software Initiated / Advertised RC
