TA790GXBE BIOS Manual
28
Hyper Transport Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Hyper Transport Configuration
UnitID Clumping [Auto]
2x LCLK Mode [Disabled]
HT Link Tristate [Auto]
Auto - CAD/CTL.
HT Link Tristate
Options: Auto (Default) / Disabled / CAD/CTL / CAD/CTL/CLK
UnitID Clumping
Options: Auto (Default) / Disabled / PCIE / GFX / PCIE & GFX
2x LCLK Mode
Options: Disabled (Default) / Enabled
Primary Video Controller
This option allows you to select the video controller in charge.
Options: PCI-GFX0-GPP-IGFX (Default) / GFX0-GPP-IGFX-PCI /
GPP-GFX0-IGFX-PCI / IGFX-GFX0-GPP-PCI
NB Power Management Features
This option controls the NB power management function.
Options: Auto (Default) / Disabled
