TA790GXBE BIOS Manual
25
Internal Graphics Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 198 5-200x, American Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Internal Graphics Configuration
UMA Frame Buffer Size [Auto]
FB Location [Above 4G]
AMD 790GX HD Audio [Enable]
Internal Graphics Mode [UMA]
Surround View [Auto]
Options
Disable
UMA
Internal Graphics Mode
This item allows you to select the memory mode used for internal graphics device.
Options: UMA (Default) / Disable
UMA Frame Buffer Size
This item allows you to choose the UMA frame buffer size for internal graphics.
Options: Auto (Default) / 32MB / 64MB / 128MB / 256MB / 512MB
Surround View
This item allows you to control the Surround View Function.
Options: Auto (Default) / Disabled
FB Location
This item allows you to set the FB-DIMM location.
Options: Above 4G (Default) / Under 4G
AMD 790GX HD Audio
This item allows you to control the northbridge HD azalia (HDMI audio) function.
Options: Enabled (Default) / Disabled
