TA790GXBE BIOS Manual
33
CPU Tuning
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, Amer ican Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
CPU Tuning
NODE0:PCI-X2 HT Link
CPU Vcore
CPU NB Over Voltage
Custom P-States [ Disabled]
HT Link Speed : [ Auto]
HT Link Width : [ Auto]
Core Leveling [ Auto]
SVID Override [ Disabled]
[Auto]
[Auto]
T-Series
CPU Vcore Control
CPU Vcore
This item allows you to select CPU Vcore Control.
Options: Auto (Default) / +0.050V ~ +1.450V (Interval: 0.05V)
CPU NB Ov er Voltage
This item allows you to select NB Over Voltage Control.
Options: Auto (Default) / +0.050V ~ +1.450V (Interval: 0.05V)
Custom P-States
This item tells BIOS whether to use the setup options below this to configure the
P-States, or whether to configure the P-States automatically.
Options: Disabled (Default) / Enabled
Core FID
This item allows you to select the Ratio/Frequency of AM2+ CPU.
Options: x8.0 1600MHz ~ x13.0 2600MHz (Differed by CPU)
