TA790GXBE BIOS Manual
24
Option ROM POST Delay
Options: Disabled (Default) / 1 ~ 7 Seconds
SATA IDE Combined Mode
This option controls the SATA/PATA combined mode.
Options: Enabled (Default) / Disabled
Power Saving Features
Disable / Enable power saving features in SB. As general rule, this feature should be
disabled for desktop and enabled for mobile. See AMD SB700 Power Saving
document for more details.
Options: Disabled (Default) / Enabled
AMD 790GX Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
AMD 790GX Configuration
CIMX Version : 4.1.0
> PCI Express Configuration
> Hyper Transport Configuration
Primary Video Controller [PCI-GFX0-GPP-IGFX]
NB Power Management Features [Auto]
> Internal Graphics Configuration
Internal Graphics Conf
