TA790GXBE BIOS Manual
29
OnBoard Peripherals Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
MAC ID Information
Realtek PCIE NIC [Enable]
Realtek Option ROM [Disabled]
Enable/Disable
Onboard RTL8111DL
PCIE Network
Controller
MAC ID Information
This area shows the MAC ID.
Realtek PCIE NIC
This option allows you to control the onboard LAN controller.
Options: Enable (Default) / Disable
Realtek Option ROM
This item allows you to enable or disable the Onboard LAN Boot ROM.
Options: Disabled (Default) / Enabled
