TA790GXBE BIOS Manual
41
DRAM Scrub Redirect
Options: Disabled (Default) / Enabled
4-bit ECC Mode
Options: Disabled (Default) / Enabled
DRAM BG Scrub/Data Cache BG Scrub/L2 Cache BG Scrub/L3 Cache BG Scrub
Options: Disabled (Default) / 40ns / 80ns / 160ns / 320ns / 640ns / 1.28us / 2.56us /
5.12us / 10.2us / 20.5us / 41.0us / 81.9us / 163.8us / 327.7us / 655.4us
G.P.U Phase Control
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
G.P.U Phase Control
Phase Status :
CPU Vcore: :
Current CPU Power :
Efficiency :
G.P.U Phase Mode [Auto]
T-Series
Options
Auto
Off
G.P.U Phase Mode
This item allows you to control G.P.U Phase Mode (power saving technology).
Options: Auto (Default) / Off
