GF8200 M2G+ BIOS Manual
12
Fan Ctrl Start Value
When CPU/System temperature arrives to the set value, the CPU/System fan will
work under Smart Fan Function mode.
Options: 0~127 (℃)
Fan Ctrl Sensitive
Incr easing the value will raise the speed of CPU/System fan.
Options: 1~127
Power Configuration
BIOS SETUP UTILITY
Advanced
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Chipset ACPI related
Configuration settings
Power Configuration
> Chipset ACPI Configuration
Suspend mode [S1 (POS)]
Repost Video on S3 Resume [NO]
ACPI Version Features [ACPI v1.0]
ACPI APIC support [Enabled]
AMI OEMB table [Enabled]
Headless mode [Disabled]
WOL From Soft-Off [Disabled]
Resume On Ring [Disabled]
Resume By RTC Alarm [Disabled]
RTC Alarm Date(Days)
System Time
USB Resume from S3/S4 [Disabled]
