GF8200 M2G+ BIOS Manual
27
Over-Voltage Configuration
BIOS SETUP U TILITY
Performance
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Over-Voltage Configuration
Processor Voltage [A uto]
CPU Over-Voltage [S tartUp]
Over-Voltage [StartUp]
Over-Voltage [1 .95V]
Chipset
HT
Memory
Over-Voltage [S tartUp]
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Options
1.350V
1.325V
1.300V
1.275V
1.250V
1.225V
1.200V
1.175V
1.150V
T
Processor Voltage
This item allows you to set the CPU voltage
Options: Auto (Default) / 0.80V ~ 1.55V (Differed by CPU)
CPU Over-Voltage
This item allows you to select CPU Voltage Control.
Options: StartUp (Default) / +3.3% / +6.6% / +10.0%
Chipset Over-Voltage
This item allows you to select NB/SB Voltage Control.
Options: StartUp (Default) / +0.050V / +0.100V / +0.150V
HT Over-Voltage
This item allows you to select HT Voltage Control.
Options: StartUp (Default) / +0.100V / +0.200V / +0.300V
Memory Over-Voltage
This item allows you to select DDR Voltage Control.
Options: StartUp (Default) / +0.050V / +0.100V / +0.150V
