GF8200 M2G+ BIOS Manual
33
CPU Frequency, MHz
This item allows you to select the CPU Frequency.
Options: 200 (MHz) (Default) / 100 ~ 500
Processor Frequency Multiplier
This item allows you to control the CPU multiplier.
Options: Auto (Default) / x4 800MHz ~ x13.5 2700MHz (Differed by CPU)
SB to K8(CPU) Freq Auto
Options: Enabled (Default) / Disabled
SB to K8(CPU) Frequency
Options: 1000 MHz (Default) / 200 MHz / 400 MHz / 600 MHz / 800 MHz
SB to K8(CPU) LinkWidth
Options: 16↓16↑ (Default) / 8↓8↑ / 4↓4↑
Memory Clock Mode
This item allows you to control the Memory Clock.
Options: Auto (Default) / Limit / Manual
MemClock Value
Options: DDR2-400MHz (Default) / DDR2-533 MHz / DDR2-667 MHz /
DDR2-800 MHz / DDR2-1066 (with AM2+ CPU)
MCP PCI-Express Frequency, MHz
Options: 100 (MHz) (Default) / 100 ~ 200
