GF8200 M2G+ BIOS Manual
25
iGPU and Ext-VGA Selection
T his item determines the working VGA device when there are two VGA devices
installed at the same time.
Options: Disable iGPU if Ext-VGA Exist (Default) / Both Exist and iGPU by
Frame Buffer Det ect
iGPU Frame Buffer Detect
This item allows you to control the iGPU frame buffer.
Options: Auto (Default) / Disabled
iGPU Frame Buffer Size
This item allows you to choose the frame buffer size o f on-chip VGA.
Options: 256MB (Default) / 32MB / 64MB / 128MB / 512MB / Disabled
PCIE Traini ng
Options: Gen2 if supported (Default) / Only Gen1
Load PMU by SW
Options: Enabled (Default) / Disabled
Chipset Thermal limit
Options: Normal (Default) / Minimum / Maximum
Hi Priority Channel
Enable or disable High Priority virtual Channel. It is only applied to Rev B Griffin
CPU.
Options: Enabled (Default) / Disabled
Display Refresh
Enable or disable display refresh virtual channel
Options: Enabled (Default) / Disabled
