GF8200 M2G+ BIOS Manual
13
Chipset ACPI Configuration
BIOS SETUP UTILITY
Advanced
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Chipset ACPI Configuration
SouthBridge ACPI HPET TABLE [Enabled]
ACPI PM Timer Width [24-bits]
Options
Disabled
Enabled
SouthBridge ACPI HPET TABLE
Options: Enabled (Default) / Disabled
ACPI PM Timer Width
Options: 24-bits (Default) / 32-bits
Suspend mode
The item allows you to select the suspend type under the ACPI operating system.
Options: S1 (POS) (Default) Power on Suspend
S3 (STR) Suspend to RAM
Auto POS+STR
Repost Video on S3 Resume
Options: NO (Default) / YES
ACPI Version Features
T he item allows you to select the version of ACPI.
Options: ACPI v1.0 (Default) / ACPI v2.0 / ACPI v3.0
