GF8200 M2G+ BIOS Manual
32
PCI Spread Spectrum
This item allows you to control the PCI spread spectrum.
Options: Disabled (Default) / Linear Down
iGPU Spread Spectrum
This item allows you to control the on-chip GPU spread spectrum.
Options: Disabled (Default) / 1.00% Tri-Center / 2.00% Tri-Center / 3.00%
Tri-Center / 5.00% Tri-Center
AMD Overclocking Configuration
T his item appears only when using AM2+ CPUs.
BIOS SETUP U TILITY
Performance
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
AMD Overclocking Configuration
Custom P-States [D isabled]
Core FID [x 12.0 2400MHz]
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Tells BIOS whether to
use the setup options
below this to
configure the
P-States, or whether
to configure the
P-States automatically
Custom P-States
This item allows you to select the P-States controlling.
Options: Disabled (Default) / Enabled
Core FID
This item allows you to select the Ratio/Frequency of AM2+ CPU.
Options: x8.0 1600MHz ~ x31.5 6300MHz (Differed by CPU)
