Control Systems
2019
Advanced control systems
Contact signal
Ai unit
(DAM101A51)
Fan
Daikin Central
Air Conditioning
System
Local
monitoring
& control
Multi-PC
Ethernet
Sub PC
Fire alarm
D -NET
D -NET
D -NET
D -NET
Wiring adaptor required for connection with
other equipment not compatible with D -NET
Via internet
Intranet/Internet
Web Access
Web Access
Malfunction report
by E-mail
HRV
VRV System
Centralised control system for easy provision of effective control
and monitoring of VRV system functions
*
1
Air Conditioning
Network Service System
(Optional Maintenance Service)
Dio unit
(DEC102A51)
Special Functions
• Features control and monitoring functions for central A/C products and an Air Conditioning
Network Service function.
• Using an external contact via DIII-NET, monitors and controls equipment such as lighting,
fans, or building security systems.
Interfacing requirements vary depending on model, and some systems may not be suitable. Please contact your distributor for details.
• Information on these systems is preliminary only. Please contact Daikin for formal information on the products.
Floor visual navigation
Graphical report
Multi-PC access
Analogue interlock
Automatic heat/cool change-over
Temperature limitation
Sliding temperature <Optional (DAM101A51) unit required>
Energy saving function (ECO mode. Power limit control) (Optional)
Air Conditioning Network Service System (Optional Maintenance Service)
New Features
New
Light
Pump
*
2
Monitor and control from the remote site by Web browser (Optional)
PPD data can be managed from the remote site by Web browser (Optional)
Send malfunction report through the Internet by E-mail (Optional)
Compliant with the RoHS Directive (DAM602B51/52)(refer to page 13 for details.)
DAM602B51/52
