Indoor Units Line Up
600 x 600 multi flow ceiling mounted cassette type
2827
FXZQ20M8/FXZQ25M8
FXZQ32M8/FXZQ40M8
FXZQ50M8
Ceiling mounted cassette (multi-flow) type
Compact, quiet and easy-to-install
Super Cassette type
Regardless of their difference in capacity, all indoor
units feature the same panel size and design, in
consideration of harmonised interior decor.
The FXFQ25M-80M
are low profile
models (246 mm)
which can be
installed in shallow
false ceilings of at
least 265 mm depth.
(220 V-240 V)(dB(A))
Single branch– 8 patterns
2 branches–2 patterns
Number of discharge outlets used
FXFQ25M-80M FXFQ100M-125M
4-way air
discharge
3-way air
discharge
2-way air
discharge
4-way air
discharge
3-way air
discharge
2-way air
discharge
Ceiling
height
Standard 2.7 m
3.0 m
3.5 m
3.0 m
3.3 m
3.5 m
3.5 m
3.8 m
–
3.2 m
3.6 m
4.2 m
3.6 m
4.0 m
4.2 m
4.2 m
4.2 m
–
High ceiling
High ceiling
Note: Set standard 4-way discharge when shipped.
High ceiling types and will be set for remote control operation.
1
2
1
2
40˚
40˚
10˚ 10˚
Pattern
2 Draft Prevention
setting
Pattern
1
Standard setting
7 discharge patterns in 2 to 4 directions can be selected to suit
the requirements of installation site or the shape of the room.
The number of installation method using branch ducts has
increased as shown below.
Piping
location
Has been set to standard setting at time of shipment.
This can be changed using the remote control.
Closed
Branched
Piping
location
Closed
Branched
25˚ 25˚
60˚
60˚
35˚
35˚
65˚
65˚
Pattern
3 Setting to prevent
soiling of ceiling
750mm
Because of the light weight construction,
suspension is easy.
Low operating sound
Installing the fresh air intake is easy using the
optional kit which requires no special chambers.
A long-life filter (maintenance free up to two
years) is equipped as a standard accessory.
Provided with high lift drain
water lift-up mechanism.
(Increased lift of drain pipe up
to 750 mm from the ceiling.)
Note: Operating sound may increase more than that when using with 3-way discharge
or 2-way discharge, or when using together with a optional kit.
:
The values of Hi mode Sound level represent those during cooling operation.
Those during heating operation are shown in brackets for two models only.
42(43) /36
125
39/33
100
36/31
80
33(34) /28
63
32/27
50
31/27
40
30/27
32
30/27
25
Operating
sound (H/L)
Class
FXFQ25M/FXFQ32M/FXFQ40M
FXFQ50M/FXFQ63M/FXFQ80M
FXFQ100M/FXFQ125M
Can also be installed in high ceilings.
There are 3 patterns in auto swing operation
Quiet, stylish unit
with a horizontal blow capability
Exactly matches the European style
architectural module
(600 mm x 600 mm).
Switch box is inside the unit, which
makes maintainance and installation
easy.
Less draft than FXFQ cassette
discharge angle:
25° to 60° 0° to 60°
Low operating sound
(240 V)(dB(A))
New model
0°
60°
0°
60°
Auto swing
Settable to 5 different
levels between 0° and 60°
Angles can be set on site to prevent drafts (0°-35°)
or soiling of the ceiling (25°-60°)
32/26
Operating
Sound (H/L)
20 25 32 40 50
32/26 34/28 37/29 42/35
Class
Compliant with the RoHS Directive
(refer to page 13 for details.)
