Ceiling suspended type
3433
Slim body with quiet and wide air flow
Ceiling mounted duct type
High static pressure allows flexible duct design
Built-in Drain Pump (optional)
Housing the drain pump inside the unit reduces the
space required for installation.
Capable of more than 150 Pa of external
static pressure (high ESP setting)
Compliant with the RoHS Directive (refer to
page 13 for details.)
Compliant with the RoHS Directive (refer to
page 13 for details.)
High external static pressure allows extensive
duct work for various applications.
Optional accessories include a drain-up kit,
high-efficiency filters (65% and 95% NBS) and
a long-life filter (maintenance free up to 1 year).
Full line-up of 8 models from 40 to 250 type.
Indoor unit
Min
450
mm
390
mm
Indoor unit
Min
530
mm
470
mm
Without drain pump
Indoor unit
470
mm
0~250
mm
222 mm
Without drain pump With drain pump
Simplified Static Pressure Control
External static pressure can be easily adjusted using
a change-over switch inside the electrical box to meet
the resistance in the duct system.
Drain-up pump is
equipped as optional
accessory with 750
mm
lift.
750
mm
120
mm
Adoption of newly designed QUIET
STREAM FAN
Drain-up kit (optional) can be easily
incorporated.
Easy-to-clean flat design
Maintenance is easier because servicing can
be performed from below the unit.
Non-dew Flap with no implanted bristles
Class
Operating sound
(H/L)
32
36/31
63
39/34
100
45/37
(220V-240V)(dB(A))
Low operating sound
Uses the quiet stream fan and many
more advanced technologies.
Sound absorption
material
Turbulent flow
is produced
Straightening vane
Quiet stream fan
Installation is easy
Maintenance is easy
Drain-up kit
(built inside main unit)
600 mm
Bristle-free Flap minimises
contamination and makes
cleaning simpler.
Non-dew Flap
100
°
New model
Wide air discharge openings produce a
spreading 100° air flow.
A long-life filter (maintenance free up to one
year) is equipped as standard accessory.
FXMQ200MA/FXMQ250MA
FXMQ40MA/FXMQ50MA
FXMQ63MA/FXMQ80MA
FXMQ100MA/FXMQ125MA
FXHQ32MA/FXHQ63MA
FXHQ100MA
Indoor Units Line Up
Compliant with the RoHS Directive (refer to
page 13 for details.)
