K8T89-A7
10
XXttrreemmee GGrraapphhiiccss PPoorrtt SSlloott:: XXGGPP11
This XGP (Extreme Graphics Port) slot is a special design that only
supports compatible AGP VGA cards.
To install the system with an add-on AGP VGA card, please make sure
to install the driver of add-on AGP VGA card before onboard VGA driver
installation. If the onboard VGA driver has already been installed before
you install the add-on AGP VGA card, the system will automatically set
the onboard VGA as the primary graphics adapter.
For the onboard VGA driver can’t be removed completely, and to solve
this problem, please follow the steps below,
1. Disable onboard VGA utility under the operating system, and reboot
PC. After PC restarts, the system will automatically set the AGP
VGA card as the graphics adapter.
2. Or, re-install your operating system to ensure the AGP VGA card
function can be used.
Note:
Please go to “http://www.biostar.com.tw” for more detailed information
about XGP compatible AGP cards.
