CHAPTER 1: INTRODUCTION
1.1 FEATURES
AA.. HHaarrddwwaarree
CPU
Supports Socket 754.
Supports AMD Athlon 64 processor up to 3700+.
Supports AMD Sempron processor.
Supports 200/400/600/800 clock rates with Double Data Rate
style operation for 400/800/1200/1600MT/s in both directions
simultaneously for Hyper Transport link.
Chipset
North Bridge: VIA K8T890.
South Bridge: VIA VT8237R.
Dimension
ATX Form Factor: 21.99cm (W) x 29.31cm (L)
Main Memory
Supports up to 2 DDR devices.
Supports 266/333/400MHz DDR devices.
Maximum memory size is up to 2GB. (Following table is only for
reference.)
DIMM Socket
Location
DDR Module
Total Memory
Size
DIMM1 128MB/256MB/512MB/1GB *1
DIMM2 128MB/256MB/512MB/1GB *1
Max is 2GB.
Slot
T hree PCI bu s m aste r sl o ts.
Two PCI-EX1 slots.
One PCI-EX16 slot.
One XGP slot (Xtreme Graphic Port). (See p.10 for detail
information)
Onboard IDE
Two IDE connectors support 4 hard disk drives.
Supports PIO mode 5, Bus Master, and Ultra DMA 66/100/133
function.
