NF500 754
3
On-board AC’97 Audio Sound Codec
Chip: ALC655:
- Compliant with AC’97 v ersion2.3 specif ication.
- Supports 6 channels audio output.
10/100 LAN
Chip: RTL8201BL / RTL8201CL.
Supports 10 Mb/s, 100 Mb/s and 1Gb/s auto-negotiation.
Prov ides the most commonly used legacy super I/O f unctionality.
Env ironment Control initiatives:
- H/W Monitor,
- Fan Speed Controller,
- ITE “Smart Guardian” function.
Security
NVIDIA Firewall technology
- Nativ e f irewall solution
Adv anced features
- Remote access, configuration, monitoring
- Command line interf ace (CLI)
- WMI scripts.
Internal On-board Connectors and Headers
1 audio-out header supports audio-out facilities.
1 f ront panel header supports front panel facilities.
1 CD-in connector supports CD-ROM audio-in function.
1 SPDIF-out connector supports digital audio-out function.
1 f loppy connector supports 2 FDD dev ices with 360K, 720K, 1.2M,
1.44M and 2.88Mbytes.
2 IDE connectors support 4 IDE disk drives.
3 USB headers support 6 USB 2.0 ports at front panel.
4 Serial ATA connectors support 4 SATA dev ices.
