Installation Manual ED721208
Installation Manual 3P291714-3
DCM601A52 iTM plus adaptor
9English
(TQPVHCEGQHK6/RNWUCFCRVQT
A
F
I
J K L MN
G H
B C D
POWER
100-240V
~
50/60Hz
LN
E
A [plus ADP IF] The terminals for connecting an intelligent Touch Manager or iTM plus
adaptor installed in parallel.
B [DIII] 6JG EQOOWPKECVKQP NKPG EQPPGEVKQP VGTOKPCNU HQT p&+++0'6q YJKEJ GPCDNGU
EQOOWPKECVKQPUYKVJ&#+-+0oUCKTEQPFKVKQPKPIGSWKROGPV
C [Di] The terminals for connecting an external signal input device for stopping air con-
ditioners in an emergency, or for connecting electric energy meters for calculating the
electricity usage of individual indoor air conditioning units.
D [RESERVE]0Q7UG
E [POWER] The power line connection terminals. These terminals are covered with a
RTQVGEVKXGEQXGT#RQYGTUWRRN[XQNVCIGQHVQ8#%CV*\KUTGSWKTGF
0GCT VJKU VGTOKPCN DNQEM VJGTG KU C DNWG TGUKP ECDNG OQWPV WUGF HQT UGEWTKPI VJG
power supply cables with cable ties.
F [plus ADP ADDRESS] The switch for selecting the address of the iTM plus adaptor.
For each iTM plus adaptor, set a unique number between 2 to 8.
G [TERM] The switch used when multiple iTM plus adaptors are connected in parallel
for enabling the termination resistor on the furthest iTM plus adaptor from the intelli-
gent Touch Manager.
H [DIII MASTER]6JGUYKVEJWUGFYJGPVJGTG CTGVYQQT OQTG&+++0'6 EGPVTCNK\GF
controllers, such as intelligent Touch Managers, are connected for distinguishing
between the “MASTER” or the “SLAVE” controllers.
I [RESET//] The switch for restarting the iTM plus adaptor.
J =6Z?)TGGP6JGKPFKECVQTVJCVKPFKECVGUYJGPQPVJCVFCVCKUDGKPIUGPVVQVJGKPVGN-
ligent Touch Manager.
K =4Z?1TCPIG6JGKPFKECVQTVJCVKPFKECVGUYJGPQPVJCVFCVCKUDGKPITGEGKXGFHTQO
the intelligent Touch Manager.
L [DIII MONITOR];GNNQY6JGKPFKECVQTVJCVKPFKECVGUYJGPQPVJCVFCVCKUDGKPIEQO-
OWPKECVGFYKVJ&+++0'6
M [CPU ALIVE])TGGP6JG.'&VJCVKPFKECVGUVJCVVJG%27KUQRGTCVKPIPQTOCNN[(QT
VJGTGNCVKQPUJKRDGVYGGPVJG.'&UVCVWUCPFVJGWPKVoUQRGTCVKPIEQPFKVKQPTGHGTVQ
the “LED status and operation” table below.
N [ALARM]4GF6JG.'&VJCVVWTPUQPQTDNKPMUKPVJGGXGPVQHCPGTTQT(QTVJGTGNC-
VKQPUJKRDGVYGGPVJG.'&UVCVWUCPFVJGWPKVoUQRGTCVKPIEQPFKVKQPTGHGTVQVJGp.'&
status and operation” table below.
