PLANET IP PBX user’s manual

2.3 On-board WAN Setup

The On-board WAN Setup page allows administrator to configure WAN network interface for PLANET

IP PBX. Select System -> On-board WAN Setup, and the current setting of WAN network interface

is displayed, e.g. type, IP address etc. Unless the “LAN Only” is selected, you can choose one of the

three options, Static IP, DHCP, and PPPoE from the Type list for your configuration. Select LAN

Only check box to disable WAN and only default router and DNS settings are applicable.

Static IP

You can click Static IP in the Type list, and manually configure the

following information:

․ IP Address

․ Netmask

․ Default gateway IP address

․ Primary, secondary or third DNS servers

Click “APPLY” to submit.

DHCP

Simply click DHCP in the Type list, and click APPLY. The acquired

IP address, netmask, and default gateway information will show

when revisit this page later.

PPPoE

1. Click PPPoE in the Type list.

2. Enter a user name and its password in User Name and

Password boxes.

3. Click “APPLY” to submit.

The PPPoE dialing will start right away. When there is an active

connection, the page will show the acquired IP address, network

mask, and default gateway information.

LAN Only

Select LAN Only to disable WAN IP settings but allow the

configuration of default gateway and primary/secondary/third DNS

servers.
