PLANET IP PBX user’s manual
Add a Device
1. Enter a device name in the Device ID box, and a URL in the
Device Administration URL box.
2. Click ADD to see the newly added device in the Device ID.
Edit a Device
Once create the device, you can modify its information through the
following steps.
1. Modify the Device Administration URL and click LINK as a
shortcut to the device administration URL.
2. Click EDIT to see the Enable Automatic Client Configuration
(ACC) page. Table 4.3.1 is a reference for detailed ACC
settings which is used for auto-configuring IP phones. One can
specify the MAC address and audio preferences of the phone.
Note that for phones using HTTP for auto-configuring, DHCP
setting needs a new option 151 with a value of http://<IP PBX
LAN IP>/tftpboot/ in the Code,Value box in Service -> DHCP
Service. No extra settings needed if the phone uses TFTP for
auto-configuring.
3. Click ENABLE to see Enable shows in the Auto Client Conf
column. Click EDIT and then DISABLE to disable the function.
Delete a Device
1. Select a Device ID.
2. Click DEL to remove the device from the Device ID.
Table 4.3.1 ACC (Automatic Client Configuration) Settings
Field Description
Device
A unique ID containing alphabets, numbers, and
underscore only without spaces; 32 characters maximum.
Vendor Prefix
Ask your IP Phone vendor for the Prefix.
MAC Address
MAC address of the device.
Supplementary Configuration
Specify if provided by the phone.
Codec Preference
Preference order of supported codec and packet times of
the phone.
Enable Voice Activity Detection
(VAD)
VAD is a technique that detects absence of audio and
conserves bandwidth by preventing the transmission of
"silent packets" over the network.
) Select if your IP Phone supports VAD.
DTMF mode
Choose a DTMF mode used by the phone
