PLANET IP PBX user’s manual

4.3.9 Extension of IP Phone

The EXTENSION MANAGEMENT page lets the administrator to create extensions. Select Device ->

Extension of IP Phone, and one can add, edit, and delete extensions. Go to Service -> IP PBX

Service, and click RELOAD to activate changes.

Add an Extension

1. Click ADD to set an extension.

2. Enter settings shown in Table 4.3.2.

3. Click ADD.

4. Click BACK to see the newly added extension.

Edit an Extension

1. Click an extension in the Extension Number.

2. Edit settings shown in Table 4.3.2.

3. Click UPDATE.

4. Click BACK to see the updated information.

Delete an Extension

1. Select an extension numbers.

2. Click DEL to remove the extension from the Extension

Number.

Table 4.3.2 Device Extension Configuration Settings

Field Description

Extension Number

A unique line number composed of digits only, e.g. 101; 32 digits

maximum. This is the login ID on the device configuration side.

Associated Device

Select the Device this extension associates with.

Password

Password of this extension. Same password must be configured

on the device side as well.

User

Select the user this extension associates with.

) If there is not any appropriate users to select, one can come

back later once the expected user has been added.

Please refer to 4.1 for details.
