PLANET IP PBX user’s manual

Select Route Management-> Route Group, and the administrator can add, edit and delete

routegroups in the ROUTE GROUP MANAGEMENT page. Go to Service -> IP PBX Service, and

click RELOAD to activate changes.

Add a Route Group

1. Type a route group name and click ADD.

2. Click the route group in Group ID to see the settings.

3. Enter settings shown in Table 4.5, and click BACK.

The newly added route group should be displayed in the Group

ID.

Edit a Route Group

1. Click a route group name in Group ID.

2. Edit settings shown in Table 4.5.

3. Click SET, if there is any update in the Description box.

4. Click BACK to see the updated information.

Delete a Route Group

1. Select a Group ID.

2. Click DEL to remove the route group from the Group ID.

Table 4.5 Routegroup Configuration Settings

Field Description

Group ID

A unique ID containing alphabets, numbers, and

underscore only without spaces; 32 characters maximum.

Description

Arbitrary description information.

Associated Routes

Select routes belonged to this routegroup. Click ADD/DEL

button to add or remove a route to or from the routegroup.

The right box lists current selected routes. Note the order of

the selected routes is important since it decides which route

would be matched first for an outgoing call.

) If there is no appropriate routes to select initially, one can

come back later to revise it, once the expected routes

are added.

Please refer to 4.4 for details.
