LAN/WAN Interface quick configurations

Nature of PLANET VIP-GW is an IP Sharing (NAT) device, it comes with two default IP addresses, and

default LAN side IP address is “192.168.0.1”, default WAN side IP address is “172.16.0.1”. You may

use any PC to connect to the LAN port of VIP-GW to start machine administration.

LAN IP address configuration via web configuration interface

Execute your web browser, and insert the IP address (default: 192.168.0.1) of VIP in the adddress bar.

After logging on machine with username/password (default: admin / 123), browse to “Advance Setup”

--> “LAN setting” configuration menu:

ÍNote

Please locate your PC in the same network segment

(192.168.0.x) of VIP-GW. If you’re not familiar with TCP/IP,

please refer to related chapter on user’s manual CD or

consult your network administrator for proper network

configurations.

In general cases, the LAN IP address is the default gateway

of LAN side workstations for Internet access, and the WAN

IP of VIP-GW are the IP address for remote calling party

to connect with.

L Hint
