Scenario 15: Gateway 2 to Gateway 1 (Remote Call PSTN number with PBX) PLAR connection
Call Method: Two-Stages-Dialing
Scenario 16: Gateway 2 to Gateway 1 (Remote Call PSTN number with PBX) PLAR connection
Call Method: One-Shot-Dialing
Gateway#1
Gateway#2
801
609, 0, 12345678
Outgoing Dial plan
No: 8x | Digit: 3~3, Des | GW2 IP address
801
WAN
SIP Call (Peer-To-Peer Mode) with PBX: Remote Call PSTN number
Method 1: Two-Stages-Dialing
Outgoing Dial plan
No: 9x | Digit: 3~3, Des | GW1 IP address
No: 6x
|
Di
g
it: 3~3
,
Des
|
GW1 IP address
x: wild card
Des: Destination IP
Digit: Digit Length min~ max
Extension 609
Extension 601
901
PSTN
Trunk-Line
02-12345678
Gateway#1 Gateway#2
801
02-12345678
Outgoing Dial plan
No: 8x | Digit: 3~3, Des | GW2 IP address
Incoming Dial Plan
No:02x | Digit: 3~10 |Strip:2|Prefix:0,,,| FXO port
801
WAN
SIP Call (Peer-To-Peer Mode) with PBX: Remote Call PSTN number
Method 2: One-Shot-Dialing
x: wild card
Des: Destination IP
Di
g
it: Di
g
it Len
g
th min~ max
Extension 609
Extension 601
901
PSTN
Trunk-Line
02-12345678
Outgoing Dial plan
No: 9x | Digit: 3~3 | Des: GW1 IP address
No: 6x | Digit: 3~3 | Des: GW1 IP address
No: 02x
|
Di
g
it: 3~10
|
Des: GW 1 IP address
