64
SIP VoIP Call: Peer-To-Peer Mode
Scenario 13: Gateway 1 to Gateway 2 PLAR connection
Scenario 14: Gateway 2 to Gateway 1 (Call PBX extension number) PLAR connection
Call Method: Two-Stages-Dialing
Gateway#1
Gateway#2
801
901
Outgoing Dial plan
No: 8x | Digit: 3~3, Des | GW1 IP address
901
801
WAN
SIP Call (Peer-To-Peer Mode)
Outgoing Dial plan
No: 9x | Digit: 3~3, Des | GW1 IP address
x: wild card
Des: Destination IP
Digit: Digit Length min~ max
Gateway#1
Gatewa
y
#2
801
609, 601
Outgoing Dial plan
No: 8x | Digit: 3~3 |Des GW2 IP address
801
WAN
SIP Call (Peer-To-Peer Mode) with PBX: Call PBX Extension
Method 1: Two-Stage-Dialing
Outgoing Dial plan
No: 9x | Digit: 3~3 |Des: GW1 IP address
No: 6x
|
Di
g
it: 3~3
|
Des: GW1 IP address
x: wild card
Des: Destination IP
Extension 609
Extension 601
901
