59
Scenario 3: Gateway 1 (with PBX/PSTN) to Gateway 2 PLAR connection
Call Method: Two-Stages-Dialing
Scenario 4: Gateway 1 (with PBX/PSTN) to Gateway 2 PLAR connection
Call Method: One-Shot-Dialing
Gateway#1
Gateway#2
801
609, 0, 12345678
Outgoing Dial plan
No: 8x
|
Di
g
it:3~3
|
Des: GW2 IP address
801
WAN
H.323 Call (Peer-To-Peer Mode) with PBX: Remote Call PSTN number
Method 1: Two-Sta
g
es-Dialin
g
Outgoing Dial plan
No: 9x | Digit: 3~3 | Des: GW1 IP address
No: 6x
|
Di
g
it:3~3
|
Des :GW1 IP address
X: wild card
Des: Destination IP
Digit: Digit Length min~ max
Extension 609
Extension 601
901
PSTN
Trunk-Line
02-12345678
Gateway#1
Gateway#2
801
02-12345678
Outgoing Dial plan
No: 8x | Digit: 3~3 |Des:GW2 IP address
Incoming Dial Plan
No: 02x| Digit:3~10 |Strip:2 |Prefix: 0,,,|FXO port
801
WAN
H.323 Call (Peer-To-Peer Mode) with PBX: Remote Call PSTN number
Method 2: One-Shot-Dialing
Outgoing Dial plan
No: 9x | Digit: 3~3 | Des: GW1 IP address
No: 6x | Digit: 3~3 | Des: GW1 IP address
No: 02x
|
Di
g
it: 3~10
|
Des: GW 1 IP address
x: wild card
Des: Destination IP
Extension 609
Extension 601
901
PSTN
Trunk-Line
02-12345678
