Other Control Si34-803_B
159 Function
[Emergency operation with settings in service mode]
∗
“Inhibition of operation” is set with each outdoor unit.
Make the following settings with the master unit. (Setting with the slave unit becomes disabled.)
∗
Discriminate the operating status of the master unit / slave units through the following LED
display.
• In order to set the master unit to operation
prohibition mode, set No. 38 of Setting mode 2 to
"MASTER OPERATION PROHIBITION".
(Procedure)
(1) Press and hold the MODE button (BS1) for a period
of 5 seconds or more.
(2) Press the SET button (BS2) 38 times.
(3) Press the RETURN button (BS3) once.
(4) Press the SET button (BS2) once.
(5) Press the RETURN button (BS3) twice.
(6) Press the MODE button (BS1) once.
• In order to set the slave unit 1 to operation
prohibition mode, set No. 39 of Setting mode 2 to
"SLAVE 1 OPERATION PROHIBITION".
(Procedure)
(1) Press and hold the MODE button (BS1) for a period
of 5 seconds or more.
(2) Press the SET button (BS2) 39 times.
(3) Press the RETURN button (BS3) once.
(4) Press the SET button (BS2) once.
(5) Press the RETURN button (BS3) twice.
(6) Press the MODE button (BS1) once.
•In order to set the slave unit 2 to operation
prohibition mode, set No. 40 of Setting mode 2 to
"SLAVE 2 OPERATION PROHIBITION".
(Procedure)
(1) Press and hold the MODE button (BS1) for a period
of 5 seconds or more.
(2) Press the SET button (BS2) 40 times.
(3) Press the RETURN button (BS3) once.
(4) Press the SET button (BS2) once.
(5) Press the RETURN button (BS3) twice.
(6) Press the MODE button (BS1) once.
∗
• In the case of multi-outdoor-unit system, “Inhibition of operation” is not set with each
compressor individually.
• In the case of multi-outdoor-unit system, when the above “Inhibition of operation” is set,
outdoor unit rotation is not functional.
Note : In order to forcedly clear the automatic backup operation, reset the power
supply with the outdoor unit in the stopped state.
LED display (
h
:ON
h
h
:OFF l:Blink)
H1P
----
H7P H8P
(Factory setting)
Master:
Slave 1:
Slave 2:
hh
hhh
hhhh
hhhh
h
hhhhhhh
hhhhhhh
l
hhhhhhh
hhhhhhh
h
h
LED display (
h
:ON
h
h
:OFF l:Blink)
H1P
----
H7P
(Factory setting)
h
hhhhhh
hhhhhh
hh
hh
hhhh
h
h
h
hhhhh
hhhhh
l
h
hhhh
hhhh
l
h
h
h
hhhhhh
hhhhhh
hh
hhh
hhhh
hhhh
LED display (
h
:ON
h
h
:OFF l:Blink)
H1P
----
H7P
(Factory setting)
h
hhhhhh
hhhhhh
hh
hh
hhhhh
h
hhhhh
hhhhh
l
h
hhhh
hhhh
l
h
h
h
hhhhhh
hhhhhh
hh
hhh
hhhh
hhhh
LED display (
h
:ON
h
h
:OFF
l
:Blink)
H1P
----
H7P
(Factory setting)
h
hhhhhh
hhhhhh
hh
h
hh
hhh
hhh
h
hhhhh
hhhhh
l
h
hhhh
hhhh
l
h
h
h
hhhhhh
hhhhhh
hh
hhh
hhhh
hhhh
