Si34-803_B Field Setting
Test Operation 204
(18) External Static Pressure Settings (for FXMQ-P model)
The “SECOND CODE NO.” is set to 07 (an external static pressure of 100 Pa) at factory set.
*1 The FXMQ50 · 63 · 80 · 100 · 125· 140PVE cannot be set to 30 Pa.
*2 The FXMQ20 · 25 · 32 · 40PVE cannot be set to 180 or 200 Pa.
(19) Setting of Direct Duct Connection
This is used when "fresh air intake kit equipped with fan" is connected. The indoor fan carries
out residual operation for one minute after the thermostat is stopped. (For the purpose of
preventing dust on the air filter from falling off.)
(20) Individual Setting of Ventilation
This is set to perform individual operation of heat reclaim ventilation using the remote controller/
central unit when heat reclaim ventilation is built in.
(Switch only when heat reclaim ventilation is built in.)
Mode No. First Code No. Second Code No.
External Static Pressure
13 (23) 6
01 30Pa (*1)
02 50Pa
03 60Pa
04 70Pa
05 80Pa
06 90Pa
07 100Pa
08 110Pa
09 120Pa
10 130Pa
11 140Pa
12 150Pa
13 160Pa
14 180Pa (*2)
15 200Pa (*2)
Mode No. First Code No. Second Code No. Contents
15 (25) 2
01
Without direct duct
connection
02
With direct duct
connection equipped
with fan
Mode No. First Code No. Second Code No. Contents
15 (25) 5
01 —
02
Individual operation of
ventilation
